Thick steel screws made from carbon steel are specifically designed for securely fastening cladding to thick steel materials, with a maximum thickness of 12mm. The #5 drill point allows for easier penetration into thick materials, facilitating cutting and reducing the effort needed for installation while ensuring precise fastening. The wafer head design provides a wide bearing surface for better load distribution, while the hex head offers greater torque and ease of installation with standard hex tools. These screws are intended for heavy-duty applications, providing robust support and reliability in demanding construction environments.
Thick steel fastening
- Carbon steel screws for fastening cladding to thick steel which thick max 12mm
- For heavy duty application
Specification:
- Gauge #12
- #12-24×38
- Head type:
- Hex Washer Flange
- Wafer
|
d (mm) |
TPI | Length | |
|
(mm) |
(inch) | ||
|
5.5 |
24 | 38 |
1-1/2” |
Drill point: #3
Washer: E.P.D.M
Coating: Ruspert
SST 500 – 2000h
Kesternich 7 – 20 cycles
Adapter in use: Magnetic Hex Socket (5/16’)
No of products
- SD-10.1.HEW-1238.B
- SD-11.1.WNW-1238.B
